| Environment |
Outside Plant (OSP), pole-to-pole aerial telecom, campus, industrial, road / CCTV and access networks. |
| Applications |
Self-supporting aerial distribution and backbone routes with span class up to 100 m, subject to route engineering. |
| Fiber Type |
OS2 G.652.D standard; G.657.A1 / G.657.A2 optional; OM3 / OM4 / OM5 50/125 µm available upon project request. |
| Fiber Count |
Typical family range 12F to 96F. Common counts: 12F, 24F, 48F, 72F and 96F. |
| Loose Tube |
Color-coded high-modulus PBT loose tubes; dry-core or jelly-filled according to approved order, typically up to 12 fibers per tube. |
| Tube Stranding |
Loose tubes and fillers stranded around the central FRP strength member. |
| Central Strength Member |
Solid FRP (Fiber Reinforced Plastic) central strength member – dielectric. |
| Water Blocking |
Water-swellable yarn / tape and/or filling compound to prevent longitudinal water ingress. |
| Strength Members |
Aramid yarn as the primary tensile reinforcement for self-supporting aerial installation. |
| Outer Jacket |
Virgin black HDPE / MDPE PE, UV-resistant and weather-resistant outdoor grade. |
| Armor / Metallic Content |
None. Non-armored and fully all-dielectric; no steel messenger, steel tape, aluminum tape or metallic reinforcement. |
| Cable Marking |
PLANET ADSS 100, fiber count, fiber type, span class, sequential meter marking and production traceability. |
| Span Class |
Up to 100 m under the approved design load case; final route-specific sag-tension confirmation required. |
