| Product type |
24-port unloaded angled metal patch panel with shield-bonding provision for compatible keystone jacks |
| Part number |
PL-PA24SU |
| Port capacity |
24 angled front openings; sequentially identified 1 through 24 |
| Rack format |
482.6 mm (19-inch) series; front rack/cabinet mounting |
| Rack height |
1U nominal rack unit (44.45 mm); actual panel envelope shall follow the approved mechanical drawing |
| Compatible jacks |
P/N PL-KE6UPD, PL-KE6UTL, PL-KE6AUTL, PL-KE6STL, PL-KE6ASTL and PL-KE7STL; verify fit / configuration |
| Port interface |
Angled PLANET keystone aperture; exact cut-out, orientation and retention dimensions controlled by approved drawing and fit test |
| Panel construction |
Conductive, corrosion-resistant angled metal frame with black finish; exact material, thickness, coating and bonding interfaces per approved drawing / sample |
| Cable management |
Removable rear cable-management bar with tie slots. Route patch cords laterally, maintain cable bend radius and side clearance, and avoid over-tight ties |
| Port identification |
Sequential 1-24 numbering with front label / identification areas |
| Shielding / bonding |
Grounding lead included as declared. Shielded operation requires shielded jacks / cable / cords, continuous termination and bonding to the designated rack / cabinet point. Unshielded jacks produce an unshielded link. Verify continuity after installation; interfaces per approved drawing / sample |
| Category / transmission |
The empty panel has no standalone Category / Class rating. Declared performance depends on compatible installed jacks, cable and cords, correct workmanship, and verified permanent-link / channel testing |
| PoE / remote power |
Passive mounting component with no standalone current rating. PoE suitability depends on the installed jacks, cable, bundling, ambient conditions and channel design |
| Installation environment |
Indoor, dry telecommunications room, rack or cabinet. Confirm rack-side clearance for lateral routing. No IP, outdoor, UV, plenum or flame-classification claim unless separately documented |
| Overall depth / weight |
Per approved angled-panel mechanical drawing and packing list; confirmation available upon request |
| Package contents |
Unloaded angled panel, removable rear cable manager and grounding lead; keystone jacks not included. Mounting hardware only as stated in the packing list |
